| Quantity: | |
|---|---|
on-Line
1 Year
7m
95L/Min
Motor
Single-Stage Pump
CSS(F)-250
Low Pressure Pump
Single Suction Pump
Vertical Pump
Verticaljoint Surface Pump
Suction Centrifugal
Semi-Open
Pump, Pumps, Circulating Pump
250W
7m
95L/Min
1.5"
230
5.1kg
Individual Color Carton
CE
MEPCATO
China
8413709190
20000PCS/Month
Available | Customized Request
| Model | Power | Caliber | Voltage/ Frequency | Max Capacity | Max Head | Length | Width | Height | |
| Input | Output | Inch | V/ Hz | L/min | m | cm | cm | cm | |
| CSS-250 | 230W | 120W | 1.5" | 230V/50Hz | 95 | 7 | 15 | 15 | 25.5 |
| CSSF-250 | 20.5 | 15 | 26 | ||||||
1. Highly efficient motor design for 24 hours continuous duty use.
2. Adopt Italian imported mechanical seal for double waterproof protection.
3. Design with Oil Chamber, provides for the most durable seal design, lubrication and cooling.
4. Motor with Thermal Protector to prevent motor failure due to pump problem or accidental run-dry conditions.
5. Internal wires connect by terminal design, solid and reliable.
6. Power cable rubber seal designed by filling epoxy to raise humidity-resistance.
7. Each pump with laser printed serial number to record the production date.
8. All pumps are 100% tested in pump head line and completed pump production line.
9. The special test all the pumps will perform is the low voltage start-up test.
| Model | Power | Caliber | Voltage/ Frequency | Max Capacity | Max Head | Length | Width | Height | |
| Input | Output | Inch | V/ Hz | L/min | m | cm | cm | cm | |
| CSS-250 | 230W | 120W | 1.5" | 230V/50Hz | 95 | 7 | 15 | 15 | 25.5 |
| CSSF-250 | 20.5 | 15 | 26 | ||||||
1. Highly efficient motor design for 24 hours continuous duty use.
2. Adopt Italian imported mechanical seal for double waterproof protection.
3. Design with Oil Chamber, provides for the most durable seal design, lubrication and cooling.
4. Motor with Thermal Protector to prevent motor failure due to pump problem or accidental run-dry conditions.
5. Internal wires connect by terminal design, solid and reliable.
6. Power cable rubber seal designed by filling epoxy to raise humidity-resistance.
7. Each pump with laser printed serial number to record the production date.
8. All pumps are 100% tested in pump head line and completed pump production line.
9. The special test all the pumps will perform is the low voltage start-up test.
