| Quantity: | |
|---|---|
on-Line
1 Year
6.5m
95L/Min
Motor
PP+Fiberglass
M-100 Low Level Submersible Utility Pump
Application
Suitable for clean water, slight dirty water and marine equipment
For domestic emergencies where a small area must be drained to the lowest level possible
Ideal for complete drainage of flat surfaces: basement, cellar, rooftops, garages, pools
Apply to fish tank and water tank cleaning
Features
Pumps residue water down to 2 mm
New A type of Auto-Manual switch can match with M-100 or M-400
Float switch models MF-100 and A type new switch model M-100A
M-100A switch: Automatic operation (A): The integrated float switch starts and stops the pump automatically when the indicator is positioned on "A".
Manual operation (M): To start the pump, lift the knob positioning the indicator on "M".
| Model | Input Power | Output Power | Outlet | Voltage | Max Flow | Max Head | L x W x H | ||
| Watt | Inch | V/Hz | L/min | m | cm | cm | cm | ||
| M-100 (Manual) | 130 | 100 | 3/4;1 | 110/230V 50/60Hz | 95 | 6.5 | 16 | 13.9 | 27 |
| MF-100 (Auto) | 18 | 13.9 | 30 | ||||||
| M-100A (Auto/Manual) | 23.2 | 13.9 | 28.5 | ||||||
Certifications
1. Highly efficient motor design for 24 hours continuous duty use.
2. Adopt Italian imported mechanical seal for double waterproof protection.
3. Design with Oil Chamber, provides for the most durable seal design, lubrication and cooling.
4. Motor with Thermal Protector to prevent motor failure due to pump problem or accidental run-dry conditions.
5. Internal wires connect by terminal design, solid and reliable.
6. Power cable rubber seal designed by filling epoxy to raise humidity-resistance.
7. Each pump with laser printed serial number to record the production date.
8. All pumps are 100% tested in pump head line and completed pump production line.
9. The special test all the pumps will perform is the low voltage start-up test.
